[VIME]Visual Iron's Mobs Edit

This mod lets you make mobs cast spells easily through an in-game visual GUI.

Whether a mob casts

A mob does not cast a spell when any of the following applies; otherwise it casts:

1. The mob has no target;
2. The target is not within the spell's min and max cast range;
3. The mob's health is not within the spell's required health range;
4. The spell is on cooldown (including the 4-second blacklist after a failed cast);
5. The mob is in its cast gap;
6. The mob's mana is lower than the spell's mana cost;
7. Attack and control spells also require the mob to have line of sight to its target.

These conditions apply per spell: if a spell fails a condition, only that spell is excluded from the draw, while other eligible spells are still drawn normally.

How a mob casts

The mob draws from its configured spells every "Cast Decision" interval (default 0.5 seconds). The chance to draw a spell is decided by its weight with the modifiers below.

Weight is probability: chance = single spell weight / (sum of all spell weights) × 100%.

Spells have 5 weight roles: Attack, Defense, Mobility, Control, Summon.

Attack

• If distance to target > "Preferred Max Range": weight × 1.5.
• If mob health < Panic Health (health percentage): weight × 0.55.

Defense

• If mob health < Panic Health: weight × 3.5.
• If Panic Health < mob health < 0.85 (percentage): weight × 1.2.
• If mob health > 0.85: weight × 0.3.

Control

• If the target is already controlled: weight × 0.4; otherwise × 1.4.
• If mob health < Panic Health: weight × 1.6.

Mobility

• If distance to target < "Preferred Min Range": weight × 2.5.
• If distance to target > "Preferred Max Range" × 1.6: weight × 1.6.
• If "Preferred Min Range" < distance to target < "Preferred Max Range" × 1.6: weight × 0.5.
• If mob health < Panic Health: weight × 1.5.

Summon

• No condition; weight × 1.4.

After a mob has cast a spell, that spell's weight is multiplied by an extra 0.35 in the next draw.

the commands:

/vime gui: open the gui

/vime reload: reload config
