Flashlight

Small Hytale plugin experiment for a player flashlight effect for future projects.

Right now the flashlight is not rendered as a real projected beam. Instead, it is simulated by tracing the player view direction, finding impact points in the world, and spawning small dynamic light entities around those hit positions. This is why it is possible to see it as a forward beam projection.

I also need to create a model for the flashlight.

Current idea

I do not currently know how to do it properly, so the current implementation uses a more practical workaround:

• read the player head direction
• trace a center ray plus a ring of extra rays
• detect nearby hit points against loaded world chunks
• pick representative hit positions
• spawn/update dynamic light entities at those positions

This gives a result that behaves more like a fake projected flashlight impact than a real render-level flashlight.

How it works

The plugin is split into a few simple parts:

• Main registers the command and the tick system
• FlashlightCommand enables, disables, or toggles the flashlight
• FlashlightTickSystem updates active flashlight players every few ticks
• FlashlightService contains the main logic
• FlashlightConeMath contains the math helpers used for beam sampling

Runtime flow

When a player runs the command:

• the player flashlight state is toggled
• the plugin syncs that player on the world thread
• every few ticks, the beam is recalculated again while the flashlight is active

Beam approximation

The beam is approximated using:

• one center ray
• a ring of rays around it

The service traces those rays forward until they hit a non-air block in a loaded chunk.

From those results:

• the center hit is preserved if it exists
• the ring hits are combined into a weighted secondary hit
• one or more dynamic light entities are spawned or updated at those positions

Why dynamic light entities

I went with spawned entities + DynamicLight because I do not currently have a proper way to render the flashlight exactly as I want.

The main problem is that what I really want is something closer to:

• a proper surface projection
• or a visible cone/beam effect
• or a shader-based overlay / post-process effect

Config

The plugin supports a config.json file for the main flashlight settings.

The config file is stored in the plugin data directory and is created automatically on first load if it does not exist yet.

It is used to adjust the main values without recompiling the plugin, such as:

• debug rendering flags
• impact light enable/disable
• player-attached light values
• beam range and beam angle
• ray step
• impact back offset
• ring ray count
• debug draw settings

If the file is missing, the plugin writes a default one automatically.
If the file already exists, the plugin loads the values from it.

Example:

{
  "debugDrawBeam": false,
  "debugShowHitPoint": false,
  "enableImpactLight": true,
  "playerLightRadius": 0,
  "playerLightRed": 0,
  "playerLightGreen": 0,
  "playerLightBlue": 0,
  "minEffectiveHitDistance": 2.0,
  "centerLightRadius": 5,
  "sideLightRadius": 2,
  "maxImpactLights": 10,
  "beamRange": 50.0,
  "beamHalfAngleDeg": 10.0,
  "rayStep": 0.08,
  "impactBackOffset": 0.15,
  "beamRingRays": 10,
  "debugDrawDurationSeconds": 0.12,
  "debugLineWidth": 0.02,
  "debugFade": false
}

Commands to activate the flashlight

/flashlight
/flashlight on
/flashlight off
